STEP 07 / 12 Coating Model DS06

Base Coating Machine

A special base coat is applied to the aluminium tube exterior, then thermally cured for firm adhesion. It covers the metallic surface and ensures clear, durable printing.

Request a quote for this machine See it in the full line
XUNTANG Base Coating Machine — real machine photo

Why this machine

Core advantages

  • Uniform coating delivers a consistent base colour
  • Stable operation ideal for high-speed production
  • Precise control prevents glue overflow
  • User-friendly operation with quick size adjustment
  • Perfect compatibility with various production lines
High outputEnergy savingSafe & stableHigh precision

Technical parameters

Base Coating Machine — DS06

Two build sizes cover the large-format and small-format tube ranges. Figures are catalogue references, confirmed against your order.

ParameterLarge modelSmall model
Tube diameterØ 19 – 35 mmØ 13.5 – 25 mm
Tube length110 – 200 mm70 – 145 mm
Production speed85 pcs/min95 pcs/min
Priming methodDry offset printing
Priming thicknessAdjustable per customer requirements
Feeding modeChain
Drying methodBaking · 180 ℃ (max 400 ℃)
Control modePLC + HMI, parameter storage
Oven power42 kW
Single-machine power8.35 kW6.9 kW
Power supply3-phase 5-wire / 380 V / 80 A
Air source0.65–0.75 MPa
Oven dimensions (L×W×H)2410 × 822 × 1980 mm2410 × 755 × 1680 mm
Dimensions3150 × 2250 × 4433 mm
Weight3600 kg
Mould change time1 hour

How it works

Equipment description

A layer of dedicated base-coat ink is applied to the outer surface of the tube body. Through thermal curing the base coat forms a uniform, firmly adhered layer on the aluminium substrate. It fully covers the metallic colour of the tube and provides an excellent printing ground for the following printing process, ensuring the clarity and adhesion of the printed pattern.
